50 Operating Instructions Cubis
®
MCE
System Settings
Parameters Setting values Explanation
DOWN.CMD. PRINT* Lower command of the gesture control corresponds to the [Print] key.
ZERO Lower command of the gesture control corresponds to the [Zero] key.
TARE Lower command of the gesture control corresponds to the [Tare] key.
IONIZER Lower command of the gesture control corresponds to the [Ionizer] key.
D.SHIELD Lower command of the gesture control corresponds to the [Change] key.
OPEN LFT. Lower command of the gesture control opens the left draft shield panel.
OPEN RT. Lower command of the gesture control opens the right draft shield panel.
OPEN TOP Lower command of the gesture control opens the upper draft shield panel.
CLOSE DS. Lower command of the gesture control closes the entire draft shield.
NONE No function is assigned to the lower command of the gesture control.
* Factory setting
Parameters in the “COM-RS232” Submenu
Parameters Setting values Explanations
DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the
weighing module.
XBPI Extended range of commands to control numerous balance functions with
binary protocol for direct communication with the weighing module.
SBI* − Enables SBI communication.
− The data is output to a PC or control unit.
− Enables the use of ESC commands from a PC to control the basic
balance functions with ASCII protocol.
OFF Deactivates the automatic data output.
BAUD 600 Sets the baud rate to 600 baud.
1200 Sets the baud rate to 1200 baud.
2400 Sets the baud rate to 2400 baud.
4800 Sets the baud rate to 4800 baud.
9600* Sets the baud rate to 9600 baud.
19200 Sets the baud rate to 19200 baud.
38400 Sets the baud rate to 38400 baud.
57600 Sets the baud rate to 57600 baud.
115200 Sets the baud rate to 115200 baud.
PARITY ODD* Applies an odd parity.
EVEN Applies an even parity.
NONE Does not apply a parity.
* Factory setting
