Sartorius Cubis Series User Manual

Shipping the Balance
Cubis MSU User Manual 155
Shipping the Balance
If repairs are required, use the original packaging to transport the balance.
To ensure adequate protection for safe shipment, Sartorius products have been
packaged to the extent necessary using environmentally friendly materials.
Only the original packaging provides optimum protection for the equipment.
t Disconnect the device from the power supply.
t Disconnect any data cables from the device.
t Remove all items (such as weights, sensors, etc.) from the weighing chamber.
1. Remove the other side draft shield panel
2. Remove the other side draft shield panel
3. Remove the upper draft shield panel
4. Remove the weighing pan
5. Remove the pan support
6. Remove the shield plate/draft shield
t On models without a draft shield: press down on the two pan support
fasteners.
t Rotate and remove the pan support.
t Place the balance in the lower part of the packaging.
2
1
3
4
5
6

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
