Sartorius Cubis Series User Manual

Equipment Supplied
t After unpacking the device and all parts, check it
immediately for any visible damage as a result of rough
handling during shipment.
If you detect any damage, proceed as directed in Section
“Care and Maintenance” under “Safety Inspection”.
t Save the box and all parts of the packaging for
any future transport.
Unplug all connected cables before packing
the equipment.
The model with the analytical draft shield comes with
the following:
1) Upper draft shield panel
2) Right draft shield panel
3) Left draft shield panel
4) Weighing pan
5) Pan support (not for MSx225.../MSx125... models)
6) Shield plate
Not pictured:
– AC adaptor
– Operating instructions (this manual)
– USB cable
The model with the milligram draft shield comes
with the following:
1) Upper draft shield panel
2) Right draft shield panel
3) Left draft shield panel
4) Weighing pan
5) Pan support
6) Shield plate
Not pictured:
– AC adaptor
– Operating instructions (this manual)
– USB cable
The model without a draft shield comes with the following:
1) Weighing pan
2) Pan support
3) Shield disk
(only for models with a readability of 10 mg)
Not pictured:
– AC adaptor
– Operating instructions (this manual)
– USB cable
10 Cubis MSU User Manual
Getting Started
1
3
4
2
5
6
1
2
3
4
5
6
1
2
3

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
