Interfaces
140 Cubis MSU User Manual
Data Output
You can define the data output parameter so that output is activated either when
a print command is received or automatically synchronized with the display
or at defined intervals (see application programs and autoprint settings).
Data Output by Print Command The print command can be transmitted by pressing P or by a software com-
mand (EscP).
Automatic Data Output In autoprint mode, data is output to the data interface port without an extra print
command. You can have synchronized data output automatically at defined display
update intervals, with or without the stability parameter. The interval time depends
on the balance operating status and balance type.
If the automatic data output is activated in the Device Configuration, it starts
immediately after the balance is turned on. You can also configure whether
the automatic data output can be stopped and started by pressing the P key.
Data Output Formats
You can output the value displayed in the measured value line and the weight unit,
with or without a data ID code. Configure this output parameter in the Device
Parameters menu (Menu > Device parameters > Configure data output > Line
format).
Example: Output Without an ID Code + 253 pcs 16 characters are printed
Example: Output Without an ID Code Qnt + 253 pcs 22 characters are printed
Data Output Format with 16 Characters
Display segments that are not activated are printed as spaces.
Display values without a decimal point are printed without a decimal point.
The type of character that can be printed depends on the character’s position.
Normal Operation
Position12345678910111213141516
+AAAAAAAAA* EEECRLF
or –..........***
or **********
*: Spaces CR: Carriage return
A: Displayed characters LF: Line feed
E: Characters for the unit
