Interfaces
Cubis MSU User Manual 141
Special Outputs
Position12345678910111213141516
******––******CRLF
or* *****A******* CRLF
or* *****AB ******CRLF
and only upon request with ESC w0 (no print command):
*****W*XXXYYYCRLF
or* *****I* XXX***CRLF
*: Spaces A = C: Calibration/Adjustment
AB = – –: Final readout W: Draft shield status (optional):
A = H: Overload I: Ionizer (optional)
AB = H H: Overload in checkweighing Y,Y,Y = Draft shield doors
A = L: Underweight XXX = Decimal value calculated from
AB = L L: Underweight in checkweighing binary data
Decimal value Binary value Control information
1
Bit0 = 0: No error/ionizer off
Bit0 = 1: Draft shield error/ionizer on
2
Bit1 = 0: Draft shield motors off
Bit1 = 1: Draft shield in motion
8
Bit3 = 0: Learning function off
Bit3 = 1: Learning function on
16
Bit4 = 0: At least one draft shield door open
Bit4 = 1: All draft shield doors closed
32
Bit6 = 0: Motorized draft shield operation
Bit6 = 1: Manual draft shield operation
R,M,L = COO: Right door closed (Closed), Middle and Left doors open (Open)
R,M,L = OCC: Right door open (Open), Middle and Left doors closed (Closed)
Error Message
Position12345678910111213141516
***Err**/###****CRLF
*:Space # # #:Error code number
Example: Output of the weight value + 111.255 g
Position12345678910111213141516
* * * 111. 255* g* * CRLF
Position 1: Plus +, or minus – or space
Position 2: Space or weight value
Position 3 – 10: Weight value with decimal point; leading zeros are output
as spaces.
Position 11: Space
Position 12 – 14: Characters for unit of measure or space
Position 15: Carriage return
Position 16: Line feed
