Importing/Exporting Data
You can use an SD memory card to move and exchange data (import/export).
This card is required when you want to save data externally or when you want
to exchange data with other balances. For example, you can easily copy user pro-
files to several balances.
Inserting Memory Cards into the Display and Control Unit
The slot for the SD card is located at the back of the display and control unit.
1. Tilt the control unit until is it nearly vertical.
2. Swivel the cover of the card slot to the front. Align the SD card so that the con-
tacts are facing down.
3. Insert the card into the slot as far as it will go.
t To remove the card, press it against the resistance in the direction of the slot
so that the card springs out.
4. Press the position retainer and swivel the display and operating unit back into
the desired position.
Import/Export Data
The following table shows what type of data can be imported and/or exported
with the SD card:
Export Import
– Global tasks xx
– User profiles with their separate tasks xx
– Menu parameters and timer-controlled functions xx
– Language files x
– Alibi memory x
– Audit trail x
– Calibration and adjustment data x
– Device information x
– Log files x
h
You can view the data from the alibi memory (xml files) with any web browser
and import them to Microsoft Excel as well.
