Sartorius Cubis Series User Manual

Task Management (TASK)
Cubis MSU User Manual 57
Configuring Printouts
You will be prompted for the printer settings with every new task you create
and can modify them as each task requires.
h
The options for printouts depend on the how the ports and their operating modes
are configured. If not all options are available, check the port configuration.
Settings for Printouts
During printout configuration the following parameters are defined:
Printout interface Peripheral ports (ComA), USB/PC (ComB), optional interface (ComC), Ethernet
(ComD)
Protocol (operating mode) Depends on the interface: Print, SBI, xBPI, SICS
Output Depends on the operating mode: Single printout or automatic (not with printer),
with/without stability
Printout criterion Manual without stability, manual with stability
Format auto. print 22characters for applications, 16characters for raw data
Standard data output Standard1 (measured value only), Standard2 (measured value and date/time),
Standard3 [date/time, weight block (N,T,G), and dotted line]
GLP printing Off, no GLP printout / For calibration/adjustment only / Always on
Print event Defines which event should trigger a print job.
The selectable print events depend on the selected application.
For basic weighing: P key, start or end of task, calibration/adjustment result.
For calculating applications: additional initialization and result.
For logging applications: additional component and evaluation
Print elements The elements to be printed also depend on the selected application. Define the
print elements for each each event, e.g., date and time, dotted line, measured
value, and the sequence in which they should be printed, etc.
Tare after printing: Off, no tare / On (automatic tare after print request)
Configuring Printouts
y When you create a new task, the printout configuration menu opens first. Sev-
eral options are not modifiable because they are preset by the interface
configuration.
The initial default setting and several examples of settings are described
in the following.

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
