142 Cubis MSU User Manual
Data Output Format with 22 Characters
When data is output in this format, ID codes with 6 characters will precede data
with a 16-character format. These six characters identify the subsequent value.
Normal Operation
1 2 3 4 5 6 7 8 9 10111213141516171819202122
KKKKKK+AAAAAAAAA*EEECRLF
******–.........****
**********
K: ID code character
1
) E: Unit symbol character
1
)
*: Space See Section “Mass Unit Conversion”
A: Displayed characters CR: Carriage return
LF: Line feed
Special Outputs
1 2 3 4 5 6 7 8 9 10111213141516171819202122
Stat********––***** *CRLF
HH
LL
C
*: Spaces L: Underweight
– –: Final readout L L: Underweight in checkweighing
H: Overload C: Calibration/Adjustment
H H: Overload in checkweighing Draft shield and ionizer status
similar to data output format with 16
characters
Error Message
1 2 3 4 5 6 7 8 9 10111213141516171819202122
Stat*****Err*###****CRLF
*:Spaces # # #:Error code number
