158 Cubis MSU User Manual
Shipping the Balance
t Place the shield plate/draft shield into the opening.
t Close the box.
Transporting the Parts (Small Analytical Draft Shield)
t Get the box ready for the individual parts of the balance.
t Get the foam pieces ready.
t Place the balance parts on top of each other.
1. Upper draft shield panel
2. Shield plate/draft shield
3. Pan support
