Sartorius Cubis Series User Manual

Removing the Side Draft Shield Panels for Milligram Balances
The side draft shield panels on milligram balances can be removed and stored at the
back of the analytical draft shield. This can be useful, for example, when perform-
ing continuous weighing or filling operations.
h
To work with an open draft shield, the ambient conditions must
be extremely stable.
t Remove the panel:
1. Press on the locking tab.
2. Remove the panel.
t Place the panel in the storage slot at the back of the balance.
28 Cubis MSU User Manual
Getting Started
2
1

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
