Sartorius Cubis Series User Manual

SQmin Minimum Weighing
Cubis MSU User Manual 69
Executing a Task: SQmin Minimum Weighing
D t If you haven’t already done so, go to Application Management.
y The task selection is displayed.
t Select the desired task.
or
t If the desired task is already marked, select Start.
y When you start a task with the SQmin function, the defined SQmin value
is shown on the display.
y As long as the weight value is lower than the SQmin value, the tab “SQmin”
will flash.

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
