Sartorius Cubis Series User Manual

Executing a Task: Calculation
D t If you haven’t already done so, go to Application Management.
y The task selection is displayed.
t Select the desired task.
or
t If the desired task is already marked, select Start.
t If you want to work with a variable formula, you can now enter or change
the formula.
t Place the sample on the balance.
y The weight value is displayed.
t To start the calculation, select Start.
y The calculation results are displayed.
t To return to the weight value display, select Weigh.
t If you want to carry out additional weighing and calculations using the same
formula, place the sample on the balance and then select Calc.
t If you want to carry out additional weighing using a different formula, select
Back.
t You can now change the formula and then proceed as described above.
84 Cubis MSU User Manual
Calculation

Sartorius Cubis Series Specifications

General

Display	Color touch screen
Readability	0.01 mg to 1 g
Interfaces	USB, Ethernet, RS-232
Calibration	Internal and external
Housing	Die-cast aluminum
Response Time	Varies by model
Pan Size	Varies by model
Operating Temperature	10°C to 30°C
Compliance	GLP
Power Supply	100 – 240 V, 50/60 Hz
Capacity	Varies by model (up to 64 kg)
Repeatability	Varies by model
Linearity	Varies by model
