4-36 Control Logic Date Code 20080110
SEL-387E Instruction Manual
Row Bit Definition
35 S3V1T Set 3 SEL OGIC control equation variable S3V1 timer output asserted
S3V2T Set 3 SEL OGIC control equation variable S3V2 timer output asserted
S3V3T Set 3 SEL OGIC control equation variable S3V3 timer output asserted
S3V4T Set 3 SEL OGIC control equation variable S3V4 timer output asserted
S3V5T Set 3 SEL OGIC control equation variable S3V5 timer output asserted
S3V6T Set 3 SEL OGIC control equation variable S3V6 timer output asserted
S3V7T Set 3 SEL OGIC control equation variable S3V7 timer output asserted
S3V8T Set 3 SEL OGIC control equation variable S3V8 timer output asserted
36 S1LT1 Set 1 latch bit S1LT1 asserted
S1LT2 Set 1 latch bit S1LT2 asserted
S1LT3 Set 1 latch bit S1LT3 asserted
S1LT4 Set 1 latch bit S1LT4 asserted
S2LT1 Set 2 latch bit S2LT1 asserted
S2LT2 Set 2 latch bit S2LT2 asserted
S2LT3 Set 2 latch bit S2LT3 asserted
S2LT4 Set 2 latch bit S2LT4 asserted
37 S3LT1 Set 3 latch bit S3LT1 asserted
S3LT2 Set 3 latch bit S3LT2 asserted
S3LT3 Set 3 latch bit S3LT3 asserted
S3LT4 Set 3 latch bit S3LT4 asserted
S3LT5 Set 3 latch bit S3LT5 asserted
S3LT6 Set 3 latch bit S3LT6 asserted
S3LT7 Set 3 latch bit S3LT7 asserted
S3LT8 Set 3 latch bit S3LT8 asserted
38 * Reserved for future use
* Reserved for future use
* Reserved for future use
50GC Combined residual current sensitivity threshold exceeded
50G3 W3 residual current sensitivity threshold exceeded
32IR 32I element reverse (external) fault declaration
32IF 32I element forward (internal) fault declaration
REFP Restricted earth fault inverse-time O/C element timed-out
