Date Code 20080110 Control Logic 4-37
SEL-387E Instruction Manual
Row Bit Definition
39 BCWA1 A-phase Breaker 1 contact wear threshold exceeded
BCWB1 B-phase Breaker 1 contact wear threshold exceeded
BCWC1 C-phase Breaker 1 contact wear threshold exceeded
BCW1 BCWA1+BCWB1+BCWC1
BCWA2 A-phase Breaker 2 contact wear threshold exceeded
BCWB2 B-phase Breaker 2 contact wear threshold exceeded
BCWC2 C-phase Breaker 2 contact wear threshold exceeded
BCW2 BCWA2+BCWB2+BCWC2
40 BCWA3 A-phase Breaker 3 contact wear threshold exceeded
BCWB3 B-phase Breaker 3 contact wear threshold exceeded
BCWC3 C-phase Breaker 3 contact wear threshold exceeded
BCW3 BCWA3+BCWB3+BCWC3
* Reserved for future use
* Reserved for future use
* Reserved for future use
* Reserved for future use
41 TRIP1 Trip 1 logic asserted
TRIP2 Trip 2 logic asserted
TRIP3 Trip 3 logic asserted
TRIP4 Trip 4 logic asserted
* Reserved for future use
TRIPL Any trip asserted
* Reserved for future use
TRGTR Target reset pushbutton/TAR R command
42 CLS1 Breaker 1 CLOSE output asserted
CLS2 Breaker 2 CLOSE output asserted
CLS3 Breaker 3 CLOSE output asserted
* Reserved for future use
CF1T Breaker 1 close failure timer timed out
CF2T Breaker 2 close failure timer timed out
CF3T Breaker 3 close failure timer timed out
* Reserved for future use
