Date Code 20080110 Control Logic 4-47
SEL-387E Instruction Manual
Bit Definition Row
OUT313 Output OUT313 asserted 47
OUT314 Output OUT314 asserted 47
OUT315 Output OUT315 asserted 47
OUT316 Output OUT216 asserted 47
PDEM1 Winding 1 phase demand current threshold exceeded 2
PDEM2 Winding 2 phase demand current threshold exceeded 6
PDEM3 Winding 3 phase demand current threshold exceeded 10
QDEM1 Winding 1 neg.-seq. demand current threshold exceeded 5
QDEM2 Winding 2 neg.-seq. demand current threshold exceeded 9
QDEM3 Winding 3 neg.-seq. demand current threshold exceeded 13
RB1 Remote bit RB1 asserted 24
RB2 Remote bit RB2 asserted 24
RB3 Remote bit RB3 asserted 24
RB4 Remote bit RB4 asserted 24
RB5 Remote bit RB5 asserted 24
RB6 Remote bit RB6 asserted 24
RB7 Remote bit RB7 asserted 24
RB8 Remote bit RB8 asserted 24
RB9 Remote bit RB9 asserted 25
RB10 Remote bit RB10 asserted 25
RB11 Remote bit RB11 asserted 25
RB12 Remote bit RB12 asserted 25
RB13 Remote bit RB13 asserted 25
RB14 Remote bit RB14 asserted 25
RB15 Remote bit RB15 asserted 25
RB16 Remote bit RB16 asserted 25
REFP Restricted earth fault inverse-time O/C element timed-out 38
S1LT1 Set 1 latch bit S1LT1 asserted 36
S1LT2 Set 1 latch bit S1LT2 asserted 36
S1LT3 Set 1 latch bit S1LT3 asserted 36
S1LT4 Set 1 latch bit S1LT4 asserted 36
S1V1 Set 1 SEL
OGIC
control equation variable S1V1 timer input asserted 32
S1V1T Set 1 SEL
OGIC
control equation variable S1V1 timer output asserted 32
S1V2 Set 1 SEL
OGIC
control equation variable S1V2 timer input asserted 32
S1V2T Set 1 SEL
OGIC
control equation variable S1V2 timer output asserted 32
S1V3 Set 1 SEL
OGIC
control equation variable S1V3 timer input asserted 32
S1V3T Set 1 SEL
OGIC
control equation variable S1V3 timer output asserted 32
S1V4 Set 1 SEL
OGIC
control equation variable S1V4 timer input asserted 32
To Next Page
