4-48 Control Logic Date Code 20080110
SEL-387E Instruction Manual
Bit Definition Row
S1V4T Set 1 SEL OGIC control equation variable S1V4 timer output asserted 32
S2LT1 Set 2 latch bit S2LT1 asserted 36
S2LT2 Set 2 latch bit S2LT2 asserted 36
S2LT3 Set 2 latch bit S2LT3 asserted 36
S2LT4 Set 2 latch bit S2LT4 asserted 36
S2V1 Set 2 SEL OGIC control equation variable S2V1 timer input asserted 33
S2V1T Set 2 SEL OGIC control equation variable S2V1 timer output asserted 33
S2V2 Set 2 SEL OGIC control equation variable S2V2 timer input asserted 33
S2V2T Set 2 SEL OGIC control equation variable S2V2 timer output asserted 33
S2V3 Set 2 SEL OGIC control equation variable S2V3 timer input asserted 33
S2V3T Set 2 SEL OGIC control equation variable S2V3 timer output asserted 33
S2V4 Set 2 SEL OGIC control equation variable S2V4 timer input asserted 33
S2V4T Set 2 SEL OGIC control equation variable S2V4 timer output asserted 33
S3LT1 Set 3 latch bit S3LT1 asserted 37
S3LT2 Set 3 latch bit S3LT2 asserted 37
S3LT3 Set 3 latch bit S3LT3 asserted 37
S3LT4 Set 3 latch bit S3LT4 asserted 37
S3LT5 Set 3 latch bit S3LT5 asserted 37
S3LT6 Set 3 latch bit S3LT6 asserted 37
S3LT7 Set 3 latch bit S3LT7 asserted 37
S3LT8 Set 3 latch bit S3LT8 asserted 37
S3V1 Set 3 SEL OGIC control equation variable S3V1 timer input asserted 34
S3V1T Set 3 SEL OGIC control equation variable S3V1 timer output asserted 35
S3V2 Set 3 SEL OGIC control equation variable S3V2 timer input asserted 34
S3V2T Set 3 SEL OGIC control equation variable S3V2 timer output asserted 35
S3V3 Set 3 SEL OGIC control equation variable S3V3 timer input asserted 34
S3V3T Set 3 SEL OGIC control equation variable S3V3 timer output asserted 35
S3V4 Set 3 SEL OGIC control equation variable S3V4 timer input asserted 34
S3V4T Set 3 SEL OGIC control equation variable S3V4 timer output asserted 35
S3V5 Set 3 SEL OGIC control equation variable S3V5 timer input asserted 34
S3V5T Set 3 SEL OGIC control equation variable S3V5 timer output asserted 35
S3V6 Set 3 SEL OGIC control equation variable S3V6 timer input asserted 34
S3V6T Set 3 SEL OGIC control equation variable S3V6 timer output asserted 35
S3V7 Set 3 SEL OGIC control equation variable S3V7 timer input asserted 34
S3V7T Set 3 SEL OGIC control equation variable S3V7 timer output asserted 35
S3V8 Set 3 SEL OGIC control equation variable S3V8 timer input asserted 34
S3V8T Set 3 SEL OGIC control equation variable S3V8 timer output asserted 35
SG1 Setting Group 1 is the active setting group 26
