SEL-387E Settings Sheets Page 15 of 28
Group Settings (SET Command) Date
Group
Date Code 20080110
S3V4 Timer Pickup (0–999999 cycles) S3V4PU =
S3V4 Timer Dropout (0–999999 cycles) S3V4DO =
Set 3 Variable 5 (SEL OGIC control equation)
S3V5 =
S3V5 Timer Pickup (0–999999 cycles) S3V5PU =
S3V5 Timer Dropout (0–999999 cycles) S3V5DO =
Set 3 Variable 6 (SEL OGIC control equation)
S3V6 =
S3V6 Timer Pickup (0–999999 cycles) S3V6PU =
S3V6 Timer Dropout (0–999999 cycles) S3V6DO =
Set 3 Variable 7 (SEL OGIC control equation)
S3V7 =
S3V7 Timer Pickup (0–999999 cycles) S3V7PU =
S3V7 Timer Dropout (0–999999 cycles) S3V7DO =
Set 3 Variable 8 (SEL OGIC control equation)
S3V8 =
S3V8 Timer Pickup (0–999999 cycles) S3V8PU =
S3V8 Timer Dropout (0–999999 cycles) S3V8DO =
Set 3 Latch Bit 1 SET Input (SEL OGIC control equation)
S3SLT1 =
Set 3 Latch Bit 1 RESET Input (SEL
OGIC control equation)
S3RLT1 =
Set 3 Latch Bit 2 SET Input (SEL
OGIC control equation)
S3SLT2 =
Set 3 Latch Bit 2 RESET Input (SEL
OGIC control equation)
S3RLT2 =
Set 3 Latch Bit 3 SET Input (SEL
OGIC control equation)
S3SLT3 =
Set 3 Latch Bit 3 RESET Input (SEL
OGIC control equation)
S3RLT3 =
Set 3 Latch Bit 4 SET Input (SEL
OGIC control equation)
S3SLT4 =
