SEL-387E Settings Sheets Page 16 of 28
Group Settings (SET Command) Date
Group
Date Code 20080110
Set 3 Latch Bit 4 RESET Input (SEL OGIC control equation)
S3RLT4 =
Set 3 Latch Bit 5 SET Input (SEL
OGIC control equation)
S3SLT5 =
Set 3 Latch Bit 5 RESET Input (SEL
OGIC control equation)
S3RLT5 =
Set 3 Latch Bit 6 SET Input (SEL
OGIC control equation)
S3SLT6 =
Set 3 Latch Bit 6 RESET Input (SEL
OGIC control equation)
S3RLT6 =
Set 3 Latch Bit 7 SET Input (SEL
OGIC control equation)
S3SLT7 =
Set 3 Latch Bit 7 RESET Input (SEL
OGIC control equation)
S3RLT7 =
Set 3 Latch Bit 8 SET Input (SEL
OGIC control equation)
S3SLT8 =
Set 3 Latch Bit 8 RESET Input (SEL
OGIC control equation)
S3RLT8 =
T RIP L OGIC
TR1 =
TR2 =
TR3 =
TR4 =
ULTR1 =
ULTR2 =
ULTR3 =
ULTR4 =
C LOSE L OGIC
52A1 =
52A2 =
52A3 =
CL1 =
CL2 =
