SEL-387E Relay Settings Sheet Page 18 of 28
Global Settings (SET G Command) Date
Date Code 20080110
R ELAY S ETTINGS
Length of Event Report (15, 29, 60 cycles) LER =
Length of Pre-fault in Event Report (1 to (LER-1)) PRE =
Nominal Frequency (50, 60 Hz) NFREQ =
Phase Rotation (ABC, ACB) PHROT =
Phase Potential Connection (D, Y) DELTA_Y =
Date Format (MDY, YMD) DATE_F =
Display Update Rate (1–60 seconds) (1–60) SCROLD =
Front Panel Time-out (0–30 minutes) FP_TO =
Group Change Delay (0–900 seconds) TGR =
B ATTERY M ONITOR
DC Battery Voltage Level 1 (OFF, 20–300 Vdc) DC1P =
DC Battery Voltage Level 2 (OFF, 20–300 Vdc) DC2P =
DC Battery Voltage Level 3 (OFF, 20–300 Vdc) DC3P =
DC Battery Voltage Level 4 (OFF, 20–300 Vdc) DC4P =
B REAKER 1 M ONITOR
BKR1 Trigger Equation (SEL OGIC control equation)
BKMON1 =
Close/Open Set Point 1 max (1–65000 operations) B1COP1 =
kA Interrupted Set Point 1 min (0.1–999.0 kA primary) B1KAP1 =
Close/Open Set Point 2 max (1–65000 operations) B1COP2 =
kA Interrupted Set Point 2 min (0.1–999.0 kA primary) B1KAP2 =
Close/Open Set Point 3 max (1–65000 operations) B1COP3 =
kA Interrupted Set Point 3 min (0.1–999.0 kA primary) B1KAP3 =
B REAKER 2 M ONITOR
BKR2 Trigger Equation (SEL OGIC control equation)
BKMON2 =
Close/Open Set Point 1 max (1–65000 operations) B2COP1 =
kA Interrupted Set Point 1 min (0.1–999.0 kA primary) B2KAP1 =
Close/Open Set Point 2 max (1–65000 operations) B2COP2 =
kA Interrupted Set Point 2 min (0.1–999.0 kA primary) B2KAP2 =
