Schweitzer Engineering Laboratories SEL-387E - Page 234

SEL-387E Relay Settings Sheet Page 20 of 28
Global Settings (SET G Command) Date
Date Code 20080110
S ETTING G ROUP S ELECTION
Select Setting Group 1 (SEL OGIC control equation)
SS1 =
Select Setting Group 2 (SEL
OGIC control equation)
SS2 =
Select Setting Group 3 (SEL
OGIC control equation)
SS3 =
Select Setting Group 4 (SEL
OGIC control equation)
SS4 =
Select Setting Group 5 (SEL
OGIC control equation)
SS5 =
Select Setting Group 6 (SEL
OGIC control equation)
SS6 =
F RONT P ANEL
Energize LEDA (SEL OGIC control equation)
LEDA =
Energize LEDB (SEL
OGIC control equation)
LEDB =
Energize LEDC (SEL
OGIC control equation)
LEDC =
Show Display Point 1 (SEL
OGIC control equation)
DP1 =
DP1 Label 1 (16 characters) (Enter NA to Null) DP1_1 =
DP1 Label 0 (16 characters) (Enter NA to Null) DP1_0 =
Show Display Point 2 (SEL OGIC control equation)
DP2 =
DP2 Label 1 (16 characters) (Enter NA to Null) DP2_1 =
DP2 Label 0 (16 characters) (Enter NA to Null) DP2_0 =
Show Display Point 3 (SEL OGIC control equation)
DP3 =
DP3 Label 1 (16 characters) (Enter NA to Null) DP3_1 =
DP3 Label 0 (16 characters) (Enter NA to Null) DP3_0 =
