SEL-387E Relay Settings Sheet
Page 26 of 28
Port Settings (SET P Command)
Date
Date Code 20080110
Note: RTSCTS setting does not appear if PROTO=LMD or DNP. PREFIX, ADDR, and
SETTLE do not appear if PROTO=SEL or DNP. Only TPORT and TIDLE settings
appear if PROTO=TELNET. See Appendix C: SEL Distributed Port Switch Protocol
(LMD) for details on LMD protocol and see Appendix G: Distributed Network Protocol
(DNP3) for details on DNP protocol. To enable Telnet-to-relay communications on
PORT 5 and PORT 6, the PORT 1 PROTO setting must be set to TELNET. Setting
PROTO = TELNET disabled PORT 1 for EIA-485 communications.
P
ORT
1 (SET P 1) R
EAR
P
ANEL
, EIA-485
PLUS
IRIG-B
Port Protocol (SEL, LMD, DNP, TELNET) PROTO =
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED =
Data Bits (7, 8) BITS =
Parity Odd, Even, or None (O, E, N) PARITY =
Stop Bits (1, 2) STOP =
Time-out (for inactivity) (0–30 minutes) T_OUT =
Send auto messages to port (Y, N) AUTO =
Enable hardware handshaking (Y, N) RTSCTS =
Fast Operate Enable (Y, N) FASTOP =
Telnet Port for Relay Access (1–65534) TPORT =
Telnet Port Timeout (1–30 minutes) TIDLE =
P
ORT
2 (SET P 2) R
EAR
P
ANEL
, EIA-232
WITH
IRIG-B
Port Protocol (SEL, LMD, DNP) PROTO =
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED =
Data Bits (7, 8) BITS =
Parity Odd, Even, or None (O, E, N) PARITY =
Stop Bits (1, 2) STOP =
Time-out (for inactivity) (0–30 minutes) T_OUT =
Send auto messages to port (Y, N) AUTO =
