Schweitzer Engineering Laboratories SEL-387E - Page 241

SEL-387E Relay Settings Sheet Page 27 of 28
Port Settings (SET P Command) Date
Date Code 20080110
Enable hardware handshaking (Y, N) RTSCTS =
Fast Operate Enable (Y, N) FASTOP =
P ORT 3 (SET P 3) R EAR P ANEL , EIA-232
Port Protocol (SEL, LMD, DNP) PROTO =
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED =
Data Bits (7, 8) BITS =
Parity Odd, Even, or None (O, E, N) PARITY =
Stop Bits (1, 2) STOP =
Time-out (for inactivity) (0–30 minutes) T_OUT =
Send auto messages to port (Y, N) AUTO =
Enable hardware handshaking (Y, N) RTSCTS =
Fast Operate Enable (Y, N) FASTOP =
P ORT 4 (SET P 4) F RONT P ANEL , EIA-232
Port Protocol (SEL, LMD, DNP) PROTO =
LMD Prefix (@, #, $, %, &) PREFIX =
LMD Address (1–99) ADDR =
LMD Settling Time (0–30 seconds) SETTLE =
Baud (300, 1200, 2400, 4800, 9600, 19200) SPEED =
Data Bits (7, 8) BITS =
Parity Odd, Even, or None (O, E, N) PARITY =
Stop Bits (1, 2) STOP =
Time-out (for inactivity) (0–30 minutes) T_OUT =
Send auto messages to port (Y, N) AUTO =
Enable hardware handshaking (Y, N) RTSCTS =
Fast Operate Enable (Y, N) FASTOP =
