SEL-387E Relay Settings Sheet Page 28 of 28
Port Settings (SET P Command) Date
Date Code 20080110
P ORT 5 (SET P 5) R EAR P ANEL E THERNET ( WHEN EQUIPPED )
IP Address (xxx.xxx.xxx.xxx) IPADDR =
Subnet Mask (xxx.xxx.xxx.xxx) SUBNETM =
Default Router (xxx.xxx.xxx.xxx) DEFRTR =
Enable TCP Keep-Alive (Y, N) ETCPKA =
If ETCPKA = Y
TCP Keep-Alive Idle Range (1–20 s) KAIDLE =
TCP Keep-Alive Interval Range (1–20 s) KAINTV =
TCP Keep-Alive Count Range (1–20 s) KACNT =
Enable Telnet (Y, N) ETELNET =
If ETELNET = Y
Telnet Port for Card Access (1–65534) TPORTC =
Telnet Port Time-out (1–30 minutes) TIDLE =
Enable FTP Server (Y, N) EFTPSERV =
If EFTPSERV = Y
FTP User Name (20 characters) FTPUSER =
FTP Connect Banner FTPCBAN =
FTP Idle Time-out (5–255 minutes) FTPIDLE =
If IEC 61850 is Available
Enable IEC 61850 Protocol (Y, N) E61850 =
Enable IEC 61850 GSE (Y, N) EGSE =
