SEL-387E Relay Settings Sheet
Page 13 of 28
Group Settings (SET Command) Example
Date
Group
Date Code 20080110
S1V4 Timer Pickup (0–999999 cycles) S1V4PU = 0
S1V4 Timer Dropout (0–999999 cycles) S1V4DO = 0
Set 1 Latch Bit 1 SET Input (SEL
OGIC
control equation)
S1SLT1 = 0
Set 1 Latch Bit 1 RESET Input (SEL
OGIC
control equation)
S1RLT1 = 0
Set 1 Latch Bit 2 SET Input (SEL
OGIC
control equation)
S1SLT2 = 0
Set 1 Latch Bit 2 RESET Input (SEL
OGIC
control equation)
S1RLT2 = 0
Set 1 Latch Bit 3 SET Input (SEL
OGIC
control equation)
S1SLT3 = 0
Set 1 Latch Bit 3 RESET Input (SEL
OGIC
control equation)
S1RLT3 = 0
Set 1 Latch Bit 4 SET Input (SEL
OGIC
control equation)
S1SLT4 = 0
Set 1 Latch Bit 4 RESET Input (SEL
OGIC
control equation)
S1RLT4 = 0
SEL
OGIC
Control Equations Set 2
Set 2 Variable 1 (SEL
OGIC
control equation)
S2V1 = 0
S2V1 Timer Pickup (0–999999 cycles) S2V1PU = 0
S2V1 Timer Dropout (0–999999 cycles) S2V1DO = 0
Set 2 Variable 2 (SEL
OGIC
control equation)
S2V2 = 0
S2V2 Timer Pickup (0–999999 cycles) S2V2PU = 0
S2V2 Timer Dropout (0–999999 cycles) S2V2DO = 0
Set 2 Variable 3 (SEL
OGIC
control equation)
S2V3 = 0
S2V3 Timer Pickup (0–999999 cycles) S2V3PU = 0
S2V3 Timer Dropout (0–999999 cycles) S2V3DO = 0
Set 2 Variable 4 (SEL
OGIC
control equation)
S2V4 = 0
