SEL-387E Relay Settings Sheet Page 14 of 28
Group Settings (SET Command) Example Date
Group
Date Code 20080110
S2V4 Timer Pickup (0–999999 cycles) S2V4PU = 0
S2V4 Timer Dropout (0–999999 cycles) S2V4DO = 0
Set 2 Latch Bit 1 SET Input (SEL OGIC control equation)
S2SLT1 = 0
Set 2 Latch Bit 1 RESET Input (SEL
OGIC control equation)
S2RLT1 = 0
Set 2 Latch Bit 2 SET Input (SEL
OGIC control equation)
S2SLT2 = 0
Set 2 Latch Bit 2 RESET Input (SEL
OGIC control equation)
S2RLT2 = 0
Set 2 Latch Bit 3 SET Input (SEL
OGIC control equation)
S2SLT3 = 0
Set 2 Latch Bit 3 RESET Input (SEL
OGIC control equation)
S2RLT3 = 0
Set 2 Latch Bit 4 SET Input (SEL
OGIC control equation)
S2SLT4 = 0
Set 2 Latch Bit 4 RESET Input (SEL
OGIC control equation)
S2RLT4 = 0
SEL OGIC C ONTROL E QUATIONS S ET 3
Set 3 Variable 1 (SEL OGIC control equation)
S3V1 = 0
S3V1 Timer Pickup (0–999999 cycles) S3V1PU = 0
S3V1 Timer Dropout (0–999999 cycles) S3V1DO = 0
Set 3 Variable 2 (SEL OGIC control equation)
S3V2 = 0
S3V2 Timer Pickup (0–999999 cycles) S3V2PU = 0
S3V2 Timer Dropout (0–999999 cycles) S3V2DO = 0
Set 3 Variable 3 (SEL OGIC control equation)
S3V3 = 0
S3V3 Timer Pickup (0–999999 cycles) S3V3PU = 0
S3V3 Timer Dropout (0–999999 cycles) S3V3DO = 0
Set 3 Variable 4 (SEL OGIC control equation)
S3V4 = 0
