SEL-387E Relay Settings Sheet
Page 15 of 28
Group Settings (SET Command) Example
Date
Group
Date Code 20080110
S3V4 Timer Pickup (0–999999 cycles) S3V4PU = 0
S3V4 Timer Dropout (0–999999 cycles) S3V4DO = 0
Set 3 Variable 5 (SEL
OGIC
control equation)
S3V5 = 0
S3V5 Timer Pickup (0–999999 cycles) S3V5PU = 0
S3V5 Timer Dropout (0–999999 cycles) S3V5DO = 0
Set 3 Variable 6 (SEL
OGIC
control equation)
S3V6 = 0
S3V6 Timer Pickup (0–999999 cycles) S3V6PU = 0
S3V6 Timer Dropout (0–999999 cycles) S3V6DO = 0
Set 3 Variable 7 (SEL
OGIC
control equation)
S3V7 = 0
S3V7 Timer Pickup (0–999999 cycles) S3V7PU = 0
S3V7 Timer Dropout (0–999999 cycles) S3V7DO = 0
Set 3 Variable 8 (SEL
OGIC
control equation)
S3V8 = 0
S3V8 Timer Pickup (0–999999 cycles) S3V8PU = 0
S3V8 Timer Dropout (0–999999 cycles) S3V8DO = 0
Set 3 Latch Bit 1 SET Input (SEL
OGIC
control equation)
S3SLT1 = 0
Set 3 Latch Bit 1 RESET Input (SEL
OGIC
control equation)
S3RLT1 = 0
Set 3 Latch Bit 2 SET Input (SEL
OGIC
control equation)
S3SLT2 = 0
Set 3 Latch Bit 2 RESET Input (SEL
OGIC
control equation)
S3RLT2 = 0
Set 3 Latch Bit 3 SET Input (SEL
OGIC
control equation)
S3SLT3 = 0
Set 3 Latch Bit 3 RESET Input (SEL
OGIC
control equation)
S3RLT3 = 0
Set 3 Latch Bit 4 SET Input (SEL
OGIC
control equation)
S3SLT4 = 0
