SEL-387E Relay Settings Sheet
Page 16 of 28
Group Settings (SET Command) Example
Date
Group
Date Code 20080110
Set 3 Latch Bit 4 RESET Input (SEL
OGIC
control equation)
S3RLT4 = 0
Set 3 Latch Bit 5 SET Input (SEL
OGIC
control equation)
S3SLT5 = 0
Set 3 Latch Bit 5 RESET Input (SEL
OGIC
control equation)
S3RLT5 = 0
Set 3 Latch Bit 6 SET Input (SEL
OGIC
control equation)
S3SLT6 = 0
Set 3 Latch Bit 6 RESET Input (SEL
OGIC
control equation)
S3RLT6 = 0
Set 3 Latch Bit 7 SET Input (SEL
OGIC
control equation)
S3SLT7 = 0
Set 3 Latch Bit 7 RESET Input (SEL
OGIC
control equation)
S3RLT7 = 0
Set 3 Latch Bit 8 SET Input (SEL
OGIC
control equation)
S3SLT8 = 0
Set 3 Latch Bit 8 RESET Input (SEL
OGIC
control equation)
S3RLT8 = 0
T
RIP
L
OGIC
TR1 = 50P11T+51P1T+51Q1T+OC1
TR2 = 51P2T+51Q2T+OC2
TR3 = 50P31+51Q3T+OC3
TR4 = 87R+87U+24C2T
ULTR1 = !50P13
ULTR2 = !50P23
ULTR3 = !50P33
ULTR4 = !(50P13+50P23+50P33)
C
LOSE
L
OGIC
52A1 = IN101
52A2 = IN102
52A3 = IN103
CL1 = CC1+/IN104
CL2 = CC2+/IN105
To Next Page
