SEL-387E Relay Settings Sheet Page 17 of 28
Group Settings (SET Command) Example Date
Group
Date Code 20080110
CL3 = CC3+/IN106
ULCL1 = TRIP1+TRIP4
ULCL2 = TRIP2+TRIP4
ULCL3 = TRIP3+TRIP4
E VENT R EPORT T RIGGERING
ER = /50P11+/51P1+/51Q1+/51P2+/51Q2+/51P3
O UTPUT C ONTACT L OGIC (S TANDARD O UTPUTS )
OUT101 = TRIP1
OUT102 = TRIP2
OUT103 = TRIP3
OUT104 = TRIP4
OUT105 = CLS1
OUT106 = CLS2
OUT107 = CLS3
O UTPUT C ONTACT L OGIC (E XTRA I NTERFACE B OARD 2 OR 6)
OUT201 = 0
OUT202 = 0
OUT203 = 0
OUT204 = 0
OUT205 = 0
OUT206 = 0
OUT207 = 0
OUT208 = 0
OUT209 = 0
OUT210 = 0
OUT211 = 0
OUT212 = 0
O UTPUT C ONTACT L OGIC (E XTRA I NTERFACE B OARD 4)
OUT201 = 0
OUT202 = 0
OUT203 = 0
OUT204 = 0
