SEL-387E Relay Settings Sheet
Page 19 of 28
Global Settings (SET G Command) Example
Date
Date Code 20080110
Close/Open Set Point 3 max (1–65000 operations) B2COP3 = 12
kA Interrupted Set Point 3 min (0.1–999.0 kA primary) B2KAP3 = 20.0
B
REAKER
3 M
ONITOR
BKR3 Trigger Equation (SEL
OGIC
control equation)
BKMON3 = TRIP3 + TRIP4
Close/Open Set Point 1 max (1–65000 operations) B3COP1 = 10000
kA Interrupted Set Point 1 min (0.1–999.0 kA primary) B3KAP1 = 1.2
Close/Open Set Point 2 max (1–65000 operations) B3COP2 = 150
kA Interrupted Set Point 2 min (0.1–999.0 kA primary) B3KAP2 = 8.0
Close/Open Set Point 3 max (1–65000 operations) B3COP3 = 12
kA Interrupted Set Point 3 min (0.1–999.0 kA primary) B3KAP3 = 20.0
T
HROUGH
-F
AULT
E
VENT
M
ONITOR
Enable Through-Fault Event Winding (N, 1, 2, 3) ETHRU = N
Note: Changing setting ETHRU resets/clears through-fault event information.
Through-Fault Event Trigger (SEL
OGIC
control equation)
THRU = 0
Through-Fault I
2
t Alarm Threshold
(OFF, 0–4294967 (kA)
2
seconds)
ISQT = OFF
A
NALOG
I
NPUT
L
ABELS
Rename Current Input IAW1 (1–4 characters) IAW1 = IAW1
Rename Current Input IBW1 (1–4 characters) IBW1 = IBW1
Rename Current Input ICW1 (1–4 characters) ICW1 = ICW1
Rename Current Input IAW2 (1–4 characters) IAW2 = IAW2
Rename Current Input IBW2 (1–4 characters) IBW2 = IBW2
Rename Current Input ICW2 (1–4 characters) ICW2 = ICW2
Rename Current Input IAW3 (1–4 characters) IAW3 = IAW3
Rename Current Input IBW3 (1–4 characters) IBW3 = IBW3
Rename Current Input ICW3 (1–4 characters) ICW3 = ICW3
Rename Voltage Input VAWX (1–4 characters) VAWX = VAWX
Rename Voltage Input VBWX (1–4 characters) VBWX = VBWX
Rename Voltage Input VCWX (1–4 characters) VCWX = VCWX
