SEL-387E Relay Settings Sheet
Page 20 of 28
Global Settings (SET G Command) Example
Date
Date Code 20080110
S
ETTING
G
ROUP
S
ELECTION
Select Setting Group 1 (SEL
OGIC
control equation)
SS1 = 0
Select Setting Group 2 (SEL
OGIC
control equation)
SS2 = 0
Select Setting Group 3 (SEL
OGIC
control equation)
SS3 = 0
Select Setting Group 4 (SEL
OGIC
control equation)
SS4 = 0
Select Setting Group 5 (SEL
OGIC
control equation)
SS5 = 0
Select Setting Group 6 (SEL
OGIC
control equation)
SS6 = 0
F
RONT
P
ANEL
Energize LEDA (SEL
OGIC
control equation)
LEDA = OCA + 87E1
Energize LEDB (SEL
OGIC
control equation)
LEDB = OCB +87E2
Energize LEDC (SEL
OGIC
control equation)
LEDC = OCC + 87E3
Show Display Point 1 (SEL
OGIC
control equation)
DP1 = IN101
DP1 Label 1 (16 characters) (Enter NA to Null) DP1_1 = BREAKER 1 CLOSED
DP1 Label 0 (16 characters) (Enter NA to Null) DP1_0 = BREAKER 1 OPEN
Show Display Point 2 (SEL
OGIC
control equation)
DP2 = IN102
DP2 Label 1 (16 characters) (Enter NA to Null) DP2_1 = BREAKER 2 CLOSED
DP2 Label 0 (16 characters) (Enter NA to Null) DP2_0 = BREAKER 2 OPEN
Show Display Point 3 (SEL
OGIC
control equation)
DP3 = IN103
DP3 Label 1 (16 characters) (Enter NA to Null) DP3_1 = BREAKER 3 CLOSED
DP3 Label 0 (16 characters) (Enter NA to Null) DP3_0 = BREAKER 3 OPEN
