SEL-387E Relay Settings Sheet Page 21 of 28
Global Settings (SET G Command) Example Date
Date Code 20080110
Show Display Point 4 (SEL OGIC control equation)
DP4 = 0
DP4 Label 1 (16 characters) (Enter NA to Null) DP4_1 =
DP4 Label 0 (16 characters) (Enter NA to Null) DP4_0 =
Show Display Point 5 (SEL OGIC control equation)
DP5 = 0
DP5 Label 1 (16 characters) (Enter NA to Null) DP5_1 =
DP5 Label 0 (16 characters) (Enter NA to Null) DP5_0 =
Show Display Point 6 (SEL OGIC control equation)
DP6 = 0
DP6 Label 1 (16 characters) (Enter NA to Null) DP6_1 =
DP6 Label 0 (16 characters) (Enter NA to Null) DP6_0 =
Show Display Point 7 (SEL OGIC control equation)
DP7 = 0
DP7 Label 1 (16 characters) (Enter NA to Null) DP7_1 =
DP7 Label 0 (16 characters) (Enter NA to Null) DP7_0 =
Show Display Point 8 (SEL OGIC control equation)
DP8 = 0
DP8 Label 1 (16 characters) (Enter NA to Null) DP8_1 =
DP8 Label 0 (16 characters) (Enter NA to Null) DP8_0 =
Show Display Point 9 (SEL OGIC control equation)
DP9 = 0
DP9 Label 1 (16 characters) (Enter NA to Null) DP9_1 =
DP9 Label 0 (16 characters) (Enter NA to Null) DP9_0 =
Show Display Point 10 (SEL OGIC control equation)
DP10 = 0
DP10 Label 1 (16 characters) (Enter NA to Null) DP10_1 =
DP10 Label 0 (16 characters) (Enter NA to Null) DP10_0 =
Show Display Point 11 (SEL OGIC control equation)
DP11 = 0
DP11 Label 1 (16 characters) (Enter NA to Null) DP11_1 =
DP11 Label 0 (16 characters) (Enter NA to Null) DP11_0 =
