If a setting is hidden because that section of the settings is turned OFF, you cannot jump to that
setting. TERSE is very useful when making small changes to the settings. For example, the
following procedure is recommended when making a change to one setting:
Change the CTR1 Setting
=>>SET CTR1 TE <Enter>
Group 1
GENERAL DATA
Wdg 1 CT Ratio (1-50000) CTR1 = 120 ? 160 <Enter>
Wdg 2 CT Ratio (1-50000) CTR2 = 240 ? END <Enter>
Save Changes? Y <Enter>
Settings saved
Verify the CTR1 Setting
=>>SHO CTR1 <Enter>
Group 1
GENERAL DATA
CTR1 = 160 CTR2 = 240 CTR3 = 400
MVA = 100.0 ICOM = Y
W1CTC = 11 W2CTC = 11 W3CTC = 0
VWDG1 = 230.00 VWDG2 = 138.00 VWDG3 = 13.80
PTR = 100 VIWDG = 1 TPVI = Y
Issue <Ctrl + X> to Stop Scrolling
=>>
Table 7.5 lists the editing keys that you can use with the SET command.
Table 7.5: Editing Keys for SET Commands
Press Key(s) Results
^ <Enter>
Moves to previous entry in a setting category until you get to the first
entry in the category, and then it moves to previous category.
< <Enter> Moves to previous settings category when making group settings.
> <Enter> Moves to next settings category when making group settings.
<Enter> Moves to next entry.
END <Enter> Exits editing session and displays all settings (if TERSE not used).
Prompts: “SAVE CHANGES (Y/N)?” Type Y <Enter> to save
changes and exit, N <Enter> to exit without saving.
<Ctrl + X> Aborts editing session without saving changes.
OFF <Enter> Flags a setting as not applicable. Only applies to certain settings.
After you enter a setting, you are prompted for the next setting. Press <Enter> to move from
setting to setting. The settings are arranged into families of related settings to simplify setting
changes. You can start at a specific setting by entering the setting name as a parameter.
The relay checks each entry to ensure that it is within the allowable input range. If it is not, an
“Out of Range” message is generated, and the relay prompts for the setting again.
