7-36 Communications Date Code 20080110
SEL-387E Instruction Manual
The following examples demonstrate the TAR command:
=>>TAR <Enter>
Default Row is 0
EN TRIP INST 87-1 87-2 87-3 24 81
1 0 0 0 0 1 0 0
=>>TAR 8 <Enter>
Display and Change Default to Row 8
50N21 50N21T 50N22 51N2 51N2T 51N2R NDEM2 OC2
0 0 0 0 0 1 0 0
=>>TAR <Enter>
Default Row is 8
50N21 50N21T 50N22 51N2 51N2T 51N2R NDEM2 OC2
0 0 0 0 0 1 0 0
=>>TAR 8 5 <Enter>
Display Row 8 Five Times
50N21 50N21T 50N22 51N2 51N2T 51N2R NDEM2 OC2
0 0 0 0 0 1 0 0
0 0 0 0 0 1 0 0
0 0 0 0 0 1 0 0
0 0 0 0 0 1 0 0
0 0 0 0 0 1 0 0
=>>TAR RB4 X <Enter>
Display Row 24 (RB4) But Do Not Change Default
RB1 RB2 RB3 RB4 RB5 RB6 RB7 RB8
0 0 0 0 1 0 0 0
=>>TAR <Enter>
50N21 50N21T 50N22 51N2 51N2T 51N2R NDEM2 OC2
0 0 0 0 0 1 0 0
=>>TAR R <Enter>
Reset Default to Row 0
EN TRIP INST 87-1 87-2 87-3 24 81
1 0 0 0 0 0 0 0
=>>
Refer to Section 4: Control Logic for a list of the Relay Word bits and their corresponding rows.
TAR F n (Show Relay Word Targets on Front-Panel LEDs)
Access Levels 1, B, 2
The TAR F command works like the TAR command, but it also remaps the second row of target
LEDs on the front panel to follow the default row. This may be useful, for example, in testing
situations where a display on the relay front-panel LEDs of element pickup or operation may be
desired. The syntax of the TAR F command follows:
TAR F n k X <Enter>
• n specifies a new default Relay Word row by entering the number or the specific
Relay Word bit name. If n is not specified, the last default row is displayed.
• k specifies a repeat count of the command for the serial port display. The default is 1.
• X allows remapping of the LEDs to a Relay Word row without changing the default
row.
The default row number returns to 0 when the serial port times out, the QUI command is
executed, or the TAR R command is executed.
