Date Code 20080110 SEL-387E Relay Command Summary 3
SEL-387E Instruction Manual
SER m n Show rows m through n in the Sequential Events Recorder (SER) event report.
SER d1 Show rows in the Sequential Events Recorder (SER) event report for date d1.
SER d1 d2 Show rows in the Sequential Events Recorder (SER) event report from date d1 to d2.
Entry of dates is dependent on the Date Format setting DATE_F (= MDY or YMD).
SER C Clear the Sequential Events Recorder (SER) event reports from memory.
SHO n Show relay group n settings. Shows active group if n is not specified.
SHO G Show relay global settings.
SHO P Show port settings and identification of port to which user is connected.
SHO P n Show port settings for Port n (n =1, 2, 3, 4).
SHO R Show Sequential Events Recorder (SER) settings.
STA Enter STA at a serial port to obtain a status report for the relay. Enter STA over
Telnet on an optional Ethernet port to obtain a status report for the Ethernet port.
TAR n k Show Relay Word row n status (n = 0 through 41). Enter number k to scroll Relay
Word row n status k times on screen.
Append F to display targets on the front panel, second row of LEDs.
TAR R Return front-panel LED targets to regular operation and reset the tripping front-panel
targets.
TFE Displays cumulative and individual through-fault event data. The twenty (20) most
recent individual events are displayed.
TFE n Displays cumulative and individual through-fault event data. The n most recent
individual events are displayed, where n = 1 to 1200.
TFE A Displays cumulative and individual through-fault event data. All the most recent
individual events are displayed, up to 1200.
TFE C Clears/resets cumulative and individual through-fault event data.
TFE P Preloads cumulative through-fault event data.
TFE R Clears/resets cumulative and individual through-fault event data.
TIM Show or set time (24-hour time). Show time presently in the relay by entering just
TIM. Example time 22:47:36 is entered with command TIM 22:47:36.
TRI Trigger an event report.
A CCESS L EVEL B C OMMANDS
Access
Level B
Commands
The Access Level B commands allow the user to control breakers and output contacts.
All Access Level 1 commands can also be executed from Access Level B. The screen
prompt is: ==>
2AC Enter Access Level 2. If the main board password jumper (JMP24A) is not in place,
the relay prompts for the entry of the Access Level 2 password in order to enter
Access Level 2.
BRE Breaker report shows trip counters, trip currents, and wear data for up to four breakers.
BRE R n Reset trip counters, trip currents, and wear data for Breaker n (n = 1, 2, 3, A).
BRE W n Pre-set the percent contact wear for each pole of Breaker n (n = 1, 2, 3).
