9-18 Analyzing Events Date Code 20080110
SEL-387E Instruction Manual
EVE R [n, Sx, Ly[-[w]]] (parameters in [ ] are optional)
where:
n Event number; defaults to 1 if not listed, where 1 is the most recent event.
Sx Display x samples per cycle (4, 8, 16, 32, or 64); defaults to 16 if not
listed.
Ly Display y cycles of data (1 to LER); defaults to LER if not listed.
Ly- Display from cycle y to end of report.
Ly-w Display from cycle y to cycle w.
Refer to
Figure 9.5 for an example raw winding event report. This example event report displays
rows of information each quarter-cycle; it was retrieved with the EVE R S4 <Enter> command.
The raw event report always shows 1.5 cycles of pretrigger data, in this case six samples instead
of four.
EVE R S4 <Enter>
XFMR 1 Date: MM/DD/YY Time: HH:MM:SS.SSS
STATION A
FID=SEL-387E-R700-V0-Z101003-D20060616
Winding 1 Winding 2 Winding 3 Winding X OUT IN
Amps Sec Amps Sec Amps Sec Volts Sec 1357 135
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2 IAW3 IBW3 ICW3 VAWX VBWX VCWX 246A 246
[0]
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
[1]
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
[2]
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 >.... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 *.... ...
.
.
.
[15]
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
+1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 +1234 .... ...
Event: TRIP1 TRIP2 TRIP3 TRIP4
Targets: TRIP INST 87-1 87-2 87-3 24 81 50/51 A B C N W1 W2 W3
Winding 1 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding 2 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding 3 Currents (A Sec), ABC: 123.1 123.1 123.1
Winding X Voltages (V Sec), ABC: 123.1 123.1 123.1
Volts/Hertz Percent: 123.1
=>>
Figure 9.5: Example Raw Winding Event Report
