Maximum Data Link Frame Size (octets):
Transmitted 292
Received (must be 292)
Maximum Application Fragment Size
(octets):
Transmitted 2048
(if >2048, must
be configurable)
Received 2048
(must be >249)
Maximum Data Link Re-tries:
None
Fixed at
; Configurable, range 0
to 15
Maximum Application Layer Re-tries:
; None
Configurable, range
to
(Fixed is not permitted)
Requires Data Link Layer Confirmation:
Never
Always
Sometimes If 'Sometimes', when?
; Configurable If 'Configurable', how? by settings.
Requires Application Layer Confirmation:
Never
Always (not recommended)
; When reporting Event Data (Slave devices only)
When sending multi-fragment responses (Slave devices only)
Sometimes If 'Sometimes', when?
Configurable If 'Configurable', how?
Time-outs while waiting for:
Data Link Confirm None Fixed at
Variable ; Configurable
Complete Appl. Fragment ; None Fixed at
Variable Configurable
Application Confirm None Fixed at
Variable ; Configurable
Complete Appl. Response ; None Fixed at
Variable Configurable
Others
Attach explanation if 'Variable' or 'Configurable' was checked for any time-out.
