Schweitzer Engineering Laboratories SEL-387E - Page 517

Date Code 20080110 Distributed Network Protocol (DNP3) G-11
SEL-387E Instruction Manual
DNP Object Type Index Description
20,22 01 Internal breaker trips 1.
20,22 02 Internal breaker trips 2.
20,22 03 Internal breaker trips 3.
20,22 04 External breaker trips 1.
20,22 05 External breaker trips 2.
20,22 06 External breaker trips 3.
30,32 00,01 IA magnitude and angle for Wdg. 1.
30,32 02,03 IB magnitude and angle for Wdg. 1.
30,32 04,05 IC magnitude and angle for Wdg. 1.
30,32 06,07 3I1 magnitude and angle for Wdg. 1.
30,32 08,09 3I2 magnitude and angle for Wdg. 1.
30,32 10,11 IRW magnitude and angle for Wdg. 1.
30,32 12,13 IA magnitude and angle for Wdg. 2.
30,32 14,15 IB magnitude and angle for Wdg. 2.
30,32 16,17 IC magnitude and angle for Wdg. 2.
30,32 18,19 3I1 magnitude and angle for Wdg. 2.
30,32 20,21 3I2 magnitude and angle for Wdg. 2.
30,32 22,23 IRW magnitude and angle for Wdg. 2.
30,32 24,25 IA magnitude and angle for Wdg. 3.
30,32 26,27 IB magnitude and angle for Wdg. 3.
30,32 28,29 IC magnitude and angle for Wdg. 3.
30,32 30,31 3I1 magnitude and angle for Wdg. 3.
30,32 32,33 3I2 magnitude and angle for Wdg. 3.
30,32 34,35 IRW magnitude and angle for Wdg. 3.
30,32 36,37 VA magnitude and angle.
30,32 38,39 VB magnitude and angle.
30,32 40,41 VC magnitude and angle.
30,32 42,43 3V1 magnitude and angle.
30,32 44,45 3V2 magnitude and angle.
30,32 46,47 3V0 magnitude and angle.
30,32 48–51 MW 3-phase, A,B,C.
30,32 52–55 MVAR 3-phase, A,B,C.
30,32 56–59 MVA 3-phase, A,B,C.
