G-12 Distributed Network Protocol (DNP3) Date Code 20080110
SEL-387E Instruction Manual
DNP Object Type Index Description
30,32 60 IOP1 Operate Current.
30,32 61 IOP2 Operate Current.
30,32 62 IOP3 Operate Current.
30,32 63 IRT1 Restraint Current.
30,32 64 IRT2 Restraint Current.
30,32 65 IRT3 Restraint Current.
30,32 66 I1F2 Second Harmonic Current.
30,32 67 I2F2 Second Harmonic Current.
30,32 68 I3F2 Second Harmonic Current.
30,32 69 I1F5 Fifth Harmonic Current.
30,32 70 I2F5 Fifth Harmonic Current.
30,32 71 I3F5 Fifth Harmonic Current.
30,32 72 Volts/Hertz.
30,32 73 Frequency.
30,32 74 VDC.
30,32 75–79 Demand A, B, C, 3I2, and IR magnitudes for Wdg. 1.
30,32 80–84 Demand A, B, C, 3I2, and IR magnitudes for Wdg. 2.
30,32 85–89 Demand A, B, C, 3I2, and IR magnitudes for Wdg. 3.
30,32 90 Peak demand IA mag. for Wdg. 1.
30 91–93 Peak demand IA time in DNP format for Wdg. 1.
30,32 94 Peak demand IB mag. for Wdg. 1.
30 95–97 Peak demand IB time in DNP format for Wdg. 1.
30,32 98 Peak demand IC mag. for Wdg. 1.
30 99–101 Peak demand IC time in DNP format for Wdg. 1.
30,32 102 Peak demand 3I2 mag. for Wdg. 1.
30 103–105 Peak demand 3I2 time in DNP format for Wdg. 1.
30,32 106 Peak demand IR mag. for Wdg. 1.
30 107–109 Peak demand IR time in DNP format for Wdg. 1.
30,32 110 Peak demand IA mag. for Wdg. 2.
30 111–113 Peak demand IA time in DNP format for Wdg. 2.
30,32 114 Peak demand IB mag. for Wdg. 2.
30 115–117 Peak demand IB time in DNP format for Wdg. 2.
30,32 118 Peak demand IC mag. for Wdg. 2.
30 119–121 Peak demand IC time in DNP format for Wdg. 2.
