Schweitzer Engineering Laboratories SEL-387E - Page 519

Date Code 20080110 Distributed Network Protocol (DNP3) G-13
SEL-387E Instruction Manual
DNP Object Type Index Description
30,32 122 Peak demand 3I2 mag. for Wdg. 2.
30 123–125 Peak demand 3I2 time in DNP format for Wdg. 2.
30,32 126 Peak demand IR mag. for Wdg. 2.
30 127–129 Peak demand IR time in DNP format for Wdg. 2.
30,32 130 Peak demand IA mag. for Wdg. 3.
30 131–133 Peak demand IA time in DNP format for Wdg. 3.
30,32 134 Peak demand IB mag. for Wdg. 3.
30 135–137 Peak demand IB time in DNP format for Wdg. 3.
30,32 138 Peak demand IC mag. for Wdg. 3.
30 139–141 Peak demand IC time in DNP format for Wdg. 3.
30,32 142 Peak demand 3I2 mag. for Wdg. 3.
30 143–145 Peak demand 3I2 time in DNP format for Wdg. 3.
30,32 146 Peak demand IR mag. for Wdg. 3.
30 147–149 Peak demand IR time in DNP format for Wdg. 3.
30,32 150–152 Breaker contact wear percentage (A, B, C) for Wdg. 1.
30,32 153–155 Breaker contact wear percentage (A, B, C) for Wdg. 2.
30,32 156–158 Breaker contact wear percentage (A, B, C) for Wdg. 3.
30,32 159 Event Type.
30,32 160 Fault Targets.
30,32 161–172 Fault values (all windings, all phases).
30,32 173 Volts/Hertz.
30,32 174 Fault settings group.
30 175–177 Fault time in DNP format (high, middle, and low 16
bits).
30,32 178,179 3-phase MWhr in and out.
30,32 180,181 A-phase MWhr in and out.
30,32 182,183 B-phase MWhr in and out.
30,32 184,185 C-phase MWhr in and out.
30,32 186,187 3-phase MVARhr in and out.
30,32 188,189 A-phase MVARhr in and out.
30,32 190,191 B-phase MVARhr in and out.
30,32 192,193 C-phase MVARhr in and out.
30 194–196 Last reset time in DNP format.
40,41 00 Active settings group.
