Date Code 20080110 IEC 61850 Communications H-7
SEL-387E Instruction Manual
Table H.4: Buffered Report Control Block Client Access
RCB Attribute
User changeable
(Report Disabled)
User changeable
(Report Enabled)
Default Values
RptId YES FALSE
RptEna YES YES FALSE
OptFlds YES SegNum
timeStamp
dataSet
reasonCode
dataRef
BufTm YES 500
TrgOp YES dchg
qchg
IntgPd YES FALSE
GI YES
ab
YES
a
FALSE
PurgeBuf YES
a
FALSE
EntryId YES 0
a
Exhibits a pulse behavior. Write a one to issue the command. Once command is accepted will
return to zero. Always read as zero.
b
When disabled, a GI will be processed and the report buffered if a buffer has been previously
established. A buffer is established when the report is enabled for the first time.
Similarly, for unbuffered reports, connected clients may edit the report parameters shown in
Table H.5.
Table H.5: Unbuffered Report Control Block Client Access
RCB Attribute
User changeable
(Report Disabled)
User changeable
(Report Enabled)
Default Values
RptId YES FALSE
RptEna YES YES FALSE
Resv YES FALSE
OptFlds YES segNum
timeStamp
dataSet
reasonCode
dataRef
BufTm YES 250
