Schweitzer Engineering Laboratories SEL-387E - Page 540

H-12 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Nodes by ICD Version
Logical
Device
Ver 001
Ver 002L
Ver 002/002L
Description
PRO Q12PIOC5 Q12PIOC5 Negative Sequence Instantaneous Overcurrent
Level 2 Element, Winding 1
PRO P22PIOC6 P22PIOC6 Phase Instantaneous Overcurrent Level 2
Element, Winding 2
PRO P23PIOC7 P23PIOC7 Phase Instantaneous Overcurrent Level 3
Element, Winding 2
PRO P24PIOC8 P24PIOC8 Phase Instantaneous Overcurrent Level 4
Element, Winding 2
PRO N22PIOC9 N22PIOC9 Residual Instantaneous Overcurrent Level 2
Element, Winding 2
PRO Q22PIOC10 Q22PIOC10 Negative Sequence Instantaneous Overcurrent
Level 2 Element, Winding 2
PRO P32PIOC11 P32PIOC11 Phase Instantaneous Overcurrent Level 2
Element, Winding 3
PRO P33PIOC12 P33PIOC12 Phase Instantaneous Overcurrent Level 3
Element, Winding 3
PRO P34PIOC13 P34PIOC13 Phase Instantaneous Overcurrent Level 4
Element, Winding 3
PRO N32PIOC14 N32PIOC14 Residual Instantaneous Overcurrent Level 2
Element, Winding 3
PRO Q32PIOC15 Q32PIOC15 Negative Sequence Instantaneous Overcurrent
Level 2 Element, Winding 3
PRO P1PTOC1 P1PTOC1 Phase Inverse-Time Overcurrent Element,
Winding 1
PRO P11PTOC2 P11PTOC2 Phase Inverse-Time Overcurrent Element
Timeout, Winding 1
PRO N1PTOC3 N1PTOC3 Phase Definite-Time Overcurrent Element,
Winding 1
PRO N11PTOC4 N11PTOC4 Phase Definite-Time Overcurrent Element
Timeout, Winding 1
PRO Q1PTOC5 Q1PTOC5 Negative-sequence Inverse-Time Overcurrent
Element, Winding 1
PRO Q11PTOC6 Q11PTOC6 Negative-sequence Inverse-Time Overcurrent
Element Timeout, Winding 1
PRO P2PTOC7 P2PTOC7 Phase Inverse-Time Overcurrent Element,
Winding 2
