Date Code 20080110 IEC 61850 Communications H-13
SEL-387E Instruction Manual
Logical Nodes by ICD Version
Logical
Device
Ver 001
Ver 002L
Ver 002/002L
Description
PRO P21PTOC8 P21PTOC8 Phase Inverse-Time Overcurrent Element
Timeout, Winding 2
PRO N2PTOC9 N2PTOC9 Phase Definite-Time Overcurrent Element,
Winding 2
PRO N21PTOC10 N21PTOC10 Phase Definite-Time Overcurrent Element
Timeout, Winding 2
PRO Q2PTOC11 Q2PTOC11 Negative-sequence Inverse-Time Overcurrent
Element, Winding 2
PRO Q21PTOC12 Q21PTOC12 Negative-sequence Inverse-Time Overcurrent
Element Timeout, Winding 2
PRO P3PTOC13 P3PTOC13 Phase Inverse-Time Overcurrent Element,
Winding 3
PRO P31PTOC14 P31PTOC14 Phase Inverse-Time Overcurrent Element
Timeout, Winding 3
PRO N3PTOC15 N3PTOC15 Phase Definite-Time Overcurrent Element,
Winding 3
PRO N31PTOC16 N31PTOC16 Phase Definite-Time Overcurrent Element
Timeout, Winding 3
PRO Q3PTOC17 Q3PTOC17 Negative-sequence Inverse-Time Overcurrent
Element, Winding 3
PRO Q31PTOC18 Q31PTOC18 Negative-sequence Inverse-Time Overcurrent
Element Timeout, Winding 3
PRO PC1PTOC19 PC1PTOC19 Phase Inverse-Time Overcurrent Element,
Windings 1 and 2
PRO NC1PTOC20 NC1PTOC20 Phase Inverse-Time Overcurrent Element
Timeout, Windings 1 and 2
PRO D87UPDIF1 D87UPDIF1 Unrestratined Differential Element
PRO D87RPDIF2 D87RPDIF2 Restrained Differential Element Operating
Current Above O87P
PRO HB2PHAR1 HB2PHAR1 Second-Harmonic Block
PRO HB5PHAR2 HB5PHAR2 Firth-Harmonic Block
PRO HBL4PHAR3 HBL4PHAR3 Fourth-Harmonic Block
PRO DCBLPHAR4 DCBLPHAR4 DC Block
PRO TRIP1PTRC1 TRIP1PTRC1 Trip 1 Logic
