H-14 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Nodes by ICD Version
Logical
Device
Ver 001
Ver 002L
Ver 002/002L
Description
PRO TRIP2PTRC2 TRIP2PTRC2 Trip 2 Logic
PRO TRIP3PTRC3 TRIP3PTRC3 Trip 3 Logic
PRO TRIP4PTRC4 TRIP4PTRC4 Trip 4 Logic
PRO P1PTUV1 P1PTUV1 Phase Undervoltage Level 1
PRO P2PTUV2 P2PTUV2 Phase Undervoltage Level 2
PRO PP1PTUV3 PP1PTUV3 Phase-Phase Undervoltage Level 1
PRO PP2PTUV4 PP2PTUV4 Phase-Phase Undervoltage Level 2
PRO V1PTUV5 V1PTUV5 Positive-Sequence Undervoltage
PRO P1PTOV1 P1PTOV1 Phase Overvoltage Level 1
PRO P2PTOV2 P2PTOV2 Phase Overvoltage Level 2
PRO PP1PTOV3 PP1PTOV3 Phase-Phase Overvoltage Level 1
PRO PP2PTOV4 PP2PTOV4 Phase-Phase Overvoltage Level 2
PRO G1PTOV5 G1PTOV5 Residual Overvoltage Level 1
PRO G2PTOV6 G2PTOV6 Residual Overvoltage Level 2
PRO QPTOV7 QPTOV7 Negative-sequence Overvoltage
PRO V1PTOV8 V1PTOV8 Positive-Sequence Overvoltage
PRO D1PVPH1 D1PVPH1 Instantaneous Volts/Hertz Level 1
PRO C2PVPH2 C2PVPH2 Composite Element Volts/Hertz Level 2
PRO W1CSWI1 W1CSWI1 Breaker 1 Control
PRO W2CSWI2 W2CSWI2 Breaker 2 Control
PRO W3CSWI3 W3CSWI3 Breaker 3 Control
PRO W1XCBR1 W1XCBR1 Breaker 1 Status
PRO W2XCBR2 W2XCBR2 Breaker 2 Status
PRO W3XCBR3 W3XCBR3 Breaker 3 Status
MET METMMXU1 METMMXU1 Measured Values (Currents and Voltages)
MET METMSQI1 METMSQI1 Positive and Zero-sequence currents and
voltages
CON RBGGIO1 RBGGIO1 Remote Bits
ANN INPUT1GGIO1 IN1GGIO1
a
Mainboard inputs
