Date Code 20080110 IEC 61850 Communications H-15
SEL-387E Instruction Manual
Logical Nodes by ICD Version
Logical
Device
Ver 001
Ver 002L
Ver 002/002L
Description
ANN INPUT2GGIO2 IN2GGIO2
a
I/O Board 2 inputs, active data only if
additional I/O Card(s) installed
ANN OUTPUT1GGIO3 OUT1GGIO3
a
Mainboard outputs
ANN OUTPUT2GGIO4 OUT2GGIO4
a
I/O Board 2 outputs, active data only if
additional I/O Card(s) installed
ANN SVGGIO5 SVGGIO5 SEL OGIC Control Variables
ANN SVTGGIO6 SVTGGIO6 SEL OGIC Timers
ANN LTGGIO7 LTGGIO7 Latch Bits
ANN TLEDGGIO8 TLEDGGIO8 Front panel target LEDs
a
Indicates that this LN name has been modified in this version and differs from the ICD file version in the adjacent left-hand column.
L OGICAL N ODES
Table H.8 through Table H.11 show the Logical Nodes (LN) supported in the SEL-387E and the
associated Relay Word bits or measured quantities.
Table H.8 shows the LNs associated with
protection elements defined as Logical Device PRO.
Table H.8: Logical Device: PRO
Logical Node (All
ICD File versions)
Status Relay Word
Bit
Comment
P12PIOC1 Op.general 50P12
P13PIOC2 Op.general 50P13
P14PIOC3 Op.general 50P14
N12PIOC4 Op.general 50N12
Q12PIOC5 Op.general 50Q12
P22PIOC6 Op.general 50P22
P23PIOC7 Op.general 50P23
P24PIOC8 Op.general 50P24
N22PIOC9 Op.general 50N22
Q22PIOC10 Op.general 50Q22
P32PIOC11 Op.general 50P32
P33PIOC12 Op.general 50P33
P34PIOC13 Op.general 50P34
