Schweitzer Engineering Laboratories SEL-387E - Page 551

Date Code 20080110 IEC 61850 Communications H-23
SEL-387E Instruction Manual
Logical Node
(All ICD File
versions)
Status Control Relay
Word Bit
Comment
RBGGIO5 SPCSO05.stVal SPCSO05.ctlVal RB5
RBGGIO6 SPCSO06.stVal SPCSO06.ctlVal RB6
RBGGIO7 SPCSO07.stVal SPCSO07.ctlVal RB7
RBGGIO8 SPCSO08.stVal SPCSO08.ctlVal RB8
RBGGIO9 SPCSO09.stVal SPCSO09.ctlVal RB9
RBGGIO10 SPCSO10.stVal SPCSO10.ctlVal RB10
RBGGIO11 SPCSO11.stVal SPCSO11.ctlVal RB11
RBGGIO12 SPCSO12.stVal SPCSO12.ctlVal RB12
RBGGIO13 SPCSO13.stVal SPCSO13.ctlVal RB13
RBGGIO14 SPCSO14.stVal SPCSO14.ctlVal RB14
RBGGIO15 SPCSO15.stVal SPCSO15.ctlVal RB15
RBGGIO16 SPCSO16.stVal SPCSO16.ctlVal RB16
Table H.11 shows the LNs associated with annunciation elements defined as Logical Device
ANN.
Table H.11: Logical Device: ANN
Logical Node
Ver 001
Ver 002L
Ver 002/002L
Status Relay
Word Bit
Comment
INPUT1GGIO1 IN1GGIO1 Ind01.stVal IN101
INPUT1GGIO1 IN1GGIO1 Ind02.stVal IN102
INPUT1GGIO1 IN1GGIO1 Ind03.stVal IN103
INPUT1GGIO1 IN1GGIO1 Ind04.stVal IN104
INPUT1GGIO1 IN1GGIO1 Ind05.stVal IN105
INPUT1GGIO1 IN1GGIO1 Ind06.stVal IN106
INPUT2GGIO2 IN2GGIO2
a
Ind01.stVal IN201
INPUT2GGIO2 IN2GGIO2
a
Ind02.stVal IN202
INPUT2GGIO2 IN2GGIO2
a
Ind03.stVal IN203
INPUT2GGIO2 IN2GGIO2
a
Ind04.stVal IN204
INPUT2GGIO2 IN2GGIO2
a
Ind05.stVal IN205
INPUT2GGIO2 IN2GGIO2
a
Ind06.stVal IN206
