H-22 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Node
(All ICD File
versions)
Measurand Comment
METMSQI1 SeqA2.c1.instCVal.mag Winding 2 positive-sequence current
magnitude
METMSQI1 SeqA2.c1.instCVal.ang Winding 2 positive-sequence current angle
METMSQI1 SeqA2.c2.instCVal.mag Winding 2 negative-sequence current
magnitude
METMSQI1 SeqA2.c2.instCVal.ang Winding 2 negative-sequence current angle
METMSQI1 SeqA2.c3.instCVal.mag Winding 2 zero-sequence current magnitude
METMSQI1 SeqA2.c3.instCVal.ang Winding 2 zero-sequence current angle
METMSQI1 SeqA3.c1.instCVal.mag Winding 3 positive-sequence current
magnitude
METMSQI1 SeqA3.c1.instCVal.ang Winding 3 positive-sequence current angle
METMSQI1 SeqA3.c2.instCVal.mag Winding 3 negative-sequence current
magnitude
METMSQI1 SeqA3.c2.instCVal.ang Winding 3 negative-sequence current angle
METMSQI1 SeqA3.c3.instCVal.mag Winding 3 zero-sequence current magnitude
METMSQI1 SeqA3.c3.instCVal.ang Winding 3 zero-sequence current angle
METMSQI1 SeqV.c1.instCVal.mag Positive-sequence voltage magnitude
METMSQI1 SeqV.c1.instCVal.ang Positive-sequence voltage angle
METMSQI1 SeqV.c2.instCVal.mag Negative-sequence voltage magnitude
METMSQI1 SeqV.c2.instCVal.ang Negative-sequence voltage angle
METMSQI1 SeqV.c3.instCVal.mag Zero-sequence voltage magnitude
METMSQI1 SeqV.c3.instCVal.ang Zero-sequence voltage angle
Table H.10 shows the LNs associated with control elements defined as Logical Device CON.
Table H.10: Logical Device: CON
Logical Node
(All ICD File
versions)
Status Control Relay
Word Bit
Comment
RBGGIO1 SPCSO01.stVal SPCSO01.ctlVal RB1
RBGGIO2 SPCSO02.stVal SPCSO02.ctlVal RB2
RBGGIO3 SPCSO03.stVal SPCSO03.ctlVal RB3
RBGGIO4 SPCSO04.stVal SPCSO04.ctlVal RB4
