Schweitzer Engineering Laboratories SEL-387E - Page 549

Date Code 20080110 IEC 61850 Communications H-21
SEL-387E Instruction Manual
Logical Node
(All ICD File
versions)
Measurand Comment
METMMXU1 A2.phsA.instCVal.mag Winding 2 A-phase current magnitude
METMMXU1 A2.phsA.instCVal.ang Winding 2 A-phase current angle
METMMXU1 A2.phsB.instCVal.mag Winding 2 B-phase current magnitude
METMMXU1 A2.phsB.instCVal.ang Winding 2 B-phase current angle
METMMXU1 A2.phsC.instCVal.mag Winding 2 C-phase current magnitude
METMMXU1 A2.phsC.instCVal.ang Winding 2 C-phase current angle
METMMXU1 A12.phsA.instCVal.mag Combined Winding 1 and 2 A-phase current
magnitude
METMMXU1 A12.phsA.instCVal.ang Combined Winding 1 and 2 A-phase current
angle
METMMXU1 A12.phsB.instCVal.mag Combined Winding 1 and 2 B-phase current
magnitude
METMMXU1 A12.phsB.instCVal.ang Combined Winding 1 and 2 B-phase current
angle
METMMXU1 A12.phsC.instCVal.mag Combined Winding 1 and 2 C-phase current
magnitude
METMMXU1 A12.phsC.instCVal.ang Combined Winding 1 and 2 C-phase current
angle
METMMXU1 A3.phsA.instCVal.mag Winding 3 A-phase current magnitude
METMMXU1 A3.phsA.instCVal.ang Winding 3 A-phase current angle
METMMXU1 A3.phsB.instCVal.mag Winding 3 B-phase current magnitude
METMMXU1 A3.phsB.instCVal.ang Winding 3 B-phase current angle
METMMXU1 A3.phsC.instCVal.mag Winding 3 C-phase current magnitude
METMMXU1 A3.phsC.instCVal.ang Winding 3 C-phase current angle
METMSQI1 SeqA1.c1.instCVal.mag Winding 1 positive-sequence current
magnitude
METMSQI1 SeqA1.c1.instCVal.ang Winding 1 positive-sequence current angle
METMSQI1 SeqA1.c2.instCVal.mag Winding 1 negative-sequence current
magnitude
METMSQI1 SeqA1.c2.instCVal.ang Winding 1 negative-sequence current angle
METMSQI1 SeqA1.c3.instCVal.mag Winding 1 zero-sequence current magnitude
METMSQI1 SeqA1.c3.instCVal.ang Winding 1 zero-sequence current angle
