H-20 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Table H.9 shows the LNs associated with measuring elements defined as Logical Device MET.
Table H.9: Logical Device: MET
Logical Node
(All ICD File
versions)
Measurand Comment
METMMXU1 TotW.instMag Three-phase MW as defined by the VIWDG
setting
METMMXU1 TotVAr.instMag Three-phase VAR as defined by the VIWDG
setting
METMMXU1 TotVA.instMag Three-phase VA as defined by the VIWDG
setting
METMMXU1 Hz.instMag Measured frequency
METMMXU1 PPV.phsAB.instCVal.mag AB-phase voltage magnitude when
DELTA_Y=D
METMMXU1 PPV.phsAB.instCVal.ang AB-phase voltage angle when DELTA_Y=D
METMMXU1 PPV.phsBC.instCVal.mag BC-phase voltage magnitude when
DELTA_Y=D
METMMXU1 PPV.phsBC.instCVal.ang BC-phase voltage angle when DELTA_Y=D
METMMXU1 PPV.phsCA.instCVal.mag CA-phase voltage magnitude when
DELTA_Y=D
METMMXU1 PPV.phsCA.instCVal.ang CA-phase voltage angle when DELTA_Y=D
METMMXU1 PhV.phsA.instCVal.mag A-phase voltage magnitude when
DELTA_Y=Y
METMMXU1 PhV.phsA.instCVal.ang A-phase voltage angle when DELTA_Y=Y
METMMXU1 PhV.phsB.instCVal.mag B-phase voltage magnitude when
DELTA_Y=Y
METMMXU1 PhV.phsB.instCVal.ang B-phase voltage angle when DELTA_Y=Y
METMMXU1 PhV.phsC.instCVal.mag C-phase voltage magnitude when
DELTA_Y=Y
METMMXU1 PhV.phsC.instCVal.ang C-phase voltage angle when DELTA_Y=Y
METMMXU1 A1.phsA.instCVal.mag Winding 1 A-phase current magnitude
METMMXU1 A1.phsA.instCVal.ang Winding 1 A-phase current angle
METMMXU1 A1.phsB.instCVal.mag Winding 1 B-phase current magnitude
METMMXU1 A1.phsB.instCVal.ang Winding 1 B-phase current angle
METMMXU1 A1.phsC.instCVal.mag Winding 1 C-phase current magnitude
METMMXU1 A1.phsC.instCVal.ang Winding 1 C-phase current angle
