Schweitzer Engineering Laboratories SEL-387E - Page 547

Date Code 20080110 IEC 61850 Communications H-19
SEL-387E Instruction Manual
Logical Node (All
ICD File versions)
Status Relay Word
Bit
Comment
V1PTOV8 Op.general 59V1
D1PVPH1 Str.general 24D1
D1PVPH1 Op.general 24D1T
C2PVPH2 Str.general 24C2
C2PVPH2 Op.general 24C2T
W1CSWI1 Pos.stVal CC1 Result of SEL OGIC setting for 52A1
W1CSWI1 Pos.Oper.ctlVal CC1 This value is actually a control
value, not a status value.
W1CSWI1 OpOpn.general OC1
W1CSWI1 OpCls.general CC1
W2CSWI2 Pos.stVal CC2 Result of SEL OGIC setting for 52A2
W2CSWI2 Pos.Oper.ctlVal CC2 This value is actually a control
value, not a status value.
W2CSWI2 OpOpn.general OC2
W2CSWI2 OpCls.general CC2
W3CSWI3 Pos.stVal CC3 Result of SEL OGIC setting for 52A3
W3CSWI3 Pos.Oper.ctlVal CC3 This value is actually a control
value, not a status value.
W3CSWI3 OpOpn.general OC3
W3CSWI3 OpCls.general CC3
W1XCBR1 OpCnt.stVal Operations count from BRE report
W1XCBR1 Pos.stVal Result of SEL OGIC setting for 52A1
W2XCBR2 OpCnt.stVal Operations count from BRE report
W2XCBR2 Pos.stVal Result of SEL OGIC setting for 52A2
W3XCBR3 OpCnt.stVal Operations count from BRE report
W3XCBR3 Pos.stVal Result of SEL OGIC setting for 52A3
