Schweitzer Engineering Laboratories SEL-387E - Page 546

H-18 IEC 61850 Communications Date Code 20080110
SEL-387E Instruction Manual
Logical Node (All
ICD File versions)
Status Relay Word
Bit
Comment
HBL4PHAR3 Str.general 4HBL
DCBLPHAR4 Str.general DCBL
TRIP1PTRC1 Tr.general TRIP1
TRIP2PTRC2 Tr.general TRIP2
TRIP3PTRC3 Tr.general TRIP3
TRIP4PTRC4 Tr.general TRIP4
P1PTUV1 Str.general 27P1
P1PTUV1 Op.general 27P1
P2PTUV2 Str.general 27P2
P2PTUV2 Op.general 27P2
PP1PTUV3 Str.general 27PP1
PP1PTUV3 Op.general 27PP1
PP2TUV4 Str.general 27PP2
PP2PTUV4 Op.general 27PP2
V1PTUV5 Str.general 27V1
V1PTUV5 Op.general 27V1
P1PTOV1 Str.general 59P1
P1PTOV1 Op.general 59P1
P2PTOV2 Str.general 59P2
P2PTOV2 Op.general 59P2
PP1PTOV3 Str.general 59PP1
PP1PTOV3 Op.general 59PP1
PP2PTOV4 Str.general 59PP2
PP2PTOV4 Op.general 59PP2
G1PTOV5 Str.general 59G1
G1PTOV5 Op.general 59G1
G2PTOV6 Str.general 59G2
G2PTOV6 Op.general 59G2
QPTOV7 Str.general 59Q
QPTOV7 Op.general 59Q
V1PTOV8 Str.general 59V1
